OC-Plan 1015 ECB Geomembrane
Please click on "Offer Request" button below to send your offer and detailed information request to the company for the OC-Plan 1015 ECB Geomembrane product.
Foundations & Walls
Terrace Roofs
Green Roofs
Below Ground Parking Lots
Water Storage Units
Ponds
Swimming Pools
Irrigation Channels
Roll dimension (DIN EN 1848-2) 2.10 m X 20 m
Actual Thickness (DIN EN 1849-2) 1.5 mm
Tear Strength (DIN EN 12310-1) ≥ 80 N
Tensile Strength (DIN EN 12311-2) ≥ 5,0 N/mm2 (method B)
Elongation (DIN EN 12311-2) ≥ %500 (method B)
Dimensional Stability (DIN EN 1107-2) across ≤ %0,3 - along ≤ 1.2%
Foldability at low T (DIN EN 495-5) ≤ - 25 C
Impact Resistance (DIN EN 12691) > 300 mm
Water Vapor Diffusion Resistance Factor (DIN EN 1931 – method B) 90.000
DIN EN, ISO, CE
EN13967
SKZ Testing GmbH
